Cylindrical Cell
- Product Information
- Code
- NiCd 7/5 A
- Catalog
- Ni-Cd Battery
- Other Details
To ask for a quotation, press
Product Introduction
Model : N1800AF
Nickel Cadmium (NiCd) Cell
Cylindrical Type
Size 7/5A
Nominal Voltage : 1.2V
Cut-off Voltage : 1.0V
Product details
| Diameter (mm) | 16.8 |
| Height (mm) | 64.5 |
Standard Charging : CC – 0.1CmA x 14-16 hrs
Standard Discharging : 0.2CmA
Max. Discharging : Continuous : 1CmA, Pulse : 2CmA
Available in bare cell or battery pack assembled with PCB pins, tags, polyswitch, NTC thermistor, thermostat, wire and/or connector
Standards (self-declare) :
1) IEC61951-1
2) IEC62133-1
